I’ve done several of these posts at this point, so simplifying these schemes has become pretty routine. I wondered if doing a VGA 256-color game would be different, but it was not.

As a reminder: I don’t really want to bypass the age protection. I like seeing it; it’s a nostalgia thing. I just don’t want to have to get the answer correct to get to the other side of it.

The patch I produced is at the bottom of this post.

Getting Started

As always, I used the excellent SCI Companion software. To spot the right script, I usually scan the text resources for tell-tale strings. This time, the background image for the quiz jumped out at me, though… number 720:

background image screenshot

Almost always, the numbers in these games line up, so background 720 goes with script 720.

The Protection Scheme

Looking at the script, I made the following observations:

  • This game uses the LARRY.DRV file for random digits just like LSL3 did.
  • The script is an event-driven state machine, like so many SCI scripts are.

Here’s the code for when you get it wrong vs right (states 2 and 3), which I’ve annotated with comments:

(2
    (if (or (== local3 local4) (== local4 0))
        (localproc_082c local3 global138)
        (gLongSong3 number: 711 play: 127)
        (proc255_0 720 13 67 200 34 25 3)
        (++ local1)                          ;; count of correct answers
        (++ state)
    else
        (localproc_082c local3 global132)
        (gLongSong3 number: 712 play:)
    )
    (= cycles 22)
)
(3
    (if (not local407)
        (++ local407)           ;; flag to say you've missed one
        (if (== local1 4)
            (proc255_0 720 14)  ;; you got close so you can still play
        else
            (proc255_0 720 15)  ;; oops, don't miss again!
        )
    else
        (proc255_0 720 16 67 -1 19 70 280)  ;; you are a kid! game over
        (= global4 1)
    )
    (= cycles 22)
)

I think I’ll just replace the (++ local407) with (++ local1) and change the (== local1 4) to (== local1 5) so that that message still works when you miss the last question. The disassembly is for that section of code is:

06d5:82 0197      lal local407
06d8:18           not
06d9:30 0025      bnt code_0701
06dc:c2 0197      +al local407   // CHANGE to C2 0001
06df:8b 01        lsl local1
06e1:35 04        ldi 4          // CHANGE to 35 05
06e3:1a           eq?
06e4:30 000d      bnt code_06f4
06e7:7a           push2
06e8:38 02d0      pushi 2d0 // $2d0 sel_720
06eb:39 0e        pushi e // $e lsLeft
06ed:47 ff 00 04  calle ff procedure_0000 4 // proc255_0
06f1:32 0027      jmp code_071b

From past experience, I’d normally use C3 01 to increment local1. However, the code I was replacing was a 3-byte C2 0197 variant. I wasn’t sure if I could use C2 on local1, but I tried it successfully on both ScummVM and DosBox.

screenshot of the patch

The Patch

Just put this 720.scr patch as 720.scr in your game directory, and it should work. I guess the VGA-era games use ${NUMBER}.scr instead of the script.${NUMBER} pattern of the EGA games.

It’s nice that this change is specific to the copy protection script, because it gives some confidence that the overall game isn’t broken by the change I made. Also, none of the original game assets were modified. That’s the nice thing about the SCI engine… it looks for uncompressed overrides of the in-game scripts on the file-system. If you delete the patch file (or rename it), the game will resume checking your answer.
